Products » PAN Accessories » Pedestal for P/PB xx speaker systems with base plate 450x450
Churches, mosques, museums, live sound reinforcement, train stations, airports, sports facilities, parliaments, conference rooms, lecture halls, shopping malls, audio/video presentation rooms.
read moreThe stand base for P / PB xx (max. two modules), with base plate 450 x 450 [mm] is designed to accommodate Pan Acoustics speaker systems up to a length of 1812 mm of the series Pan Beam, Pan Speaker, Pan AMT. The stand base is in the same design as the speaker. Visually, this forms a common unit and thus results in a successful symbiosis between architecture and sound.
For optimal alignment, the pedestal has 4 adjustable rubber feet. The pedestal module can be adjusted in fifteen-degree increments for horizontal alignment of the speaker. The speaker's connection cables can be routed in the cable channel located on the back. The cable channel also covers the speaker's connection panel so that direct access is not possible.
| Material: Base plate: Base: | Steel Aluminum |
| Supported speakers: | up to a max. length of 1812 mm and a max. weight vno 11 kg |
| Dimensions (H x W x D): base plate (without feet): base: | 450 x 450 x 15 [mm] 1138 x 107 x 118 [mm] |
| Weight: | 25 kg (incl. base plate excl. speakers). |
| Application area: | Indoor |
| Optional accessories: | Roller set |
Individual lacquering / colouring in the RAL system. Other colour systems such as RAL design, Pantone etc. are possible on request.
Individual cabinet length of the speaker is possible. The enclosures of the Pan Speaker series can be customised to customer dimensions.
Analog audio inputs with balanced signal routing
Digital audio input: supports 2 x AES/EBU (AES3) and 1 x anlaog audio (failover function)
Digital audio network DANTE incl. AES67 support. Supports redundant network structure with Pan Net control and 1 x analogue audio (failover function).
100V audio inputs with different power taps.
Pilot tone evaluation for integration in SAA/ ENS systems.
Pan Net - Pan Acoustics' proprietary control and monitoring protocol.
General Purpose Output (GPO) Switchable contact e.g. for status request by means of downstream media control.
Priority switching - Automatic switching of the audio inputs, e.g. between program and announcement.
DC input for operation on emergency power supplies.
Weatherproofing of the loudspeakers can be achieved via protection classes IP54 or IP65 (depending on the model).
Accessories such as wall, stand and ceiling mounts, various interfaces, connection cables, weather protection hoods and connection sets are available.
